Magnetic Position Sensor ICs

Products

View all products >

1. Linear Hall

SC4251

Dual-channel Angle Hall Sensor with Sine-Cosine Output

V_Q: 50%V_DD, Sensitivity: 5.0mV/Gs(V_DD=3.3V),
f_BW:30KHz, Temp:-40~125℃, D3/DN Package

Dual channel, Sine-Cosine output

SC4823

Low-Power High-Speed Linear Hall Sensor with Sleep/Wake-Up Functions

V_Q: 90%V_DD, Sensitivity: 3.0mV/Gs(V_DD=3.3V) ,-40~105℃, S6 Package

Sleep & Awake, Unipolar

SC4391

High-Speed Linear Hall Sensor with Wake-Up Function and Configurable Digital Output

V_Q: adjustable Sensitivity: 2.0~5.0mV/Gs
Temp: -40~85℃, S6/DN Package

Digital output, High Speed

SC4703

Ultra-Low Power, High-Speed Response Linear Hall Sensor

V_Q: 50%V_DD, Sensitivity: 3.0mV/Gs(V_DD=3.3V), f_BW: 250KHz, Temp:-40~105℃, SO Package

Bipolar, ultra-low power

SC4723

Ultra-Low Power, Low-Noise, High-Speed Response Linear Hall Sensor

V_Q: 85%V_DD, Sensitivity: 3.0mV/Gs
f_BW: 250KHz, Temp:-40~105℃, SO Package

Unipolar, ultra-low power

SC4101

Linear Hall Effect Sensor with Sleep Mode

V_Q: 50%V_DD, Sensitivity: 1.5mV/Gs
f_BW: 100KHz , SO/SE/DN Package

Bipolar, Sleep mode

SC4015

Wide-Range, Unipolar Magnetic Field Response High-Speed Linear Hall Sensor

V_Q: 66%V_DD, Sensitivity: 3.9mV/Gs
Temp: -40~105℃, SO Package

Unipolar, power on time<1uS

View all products >

2. Dual-Channel Switch Hall

SC2527-AB

Dual-Channel Speed and Speed Output Hall Sensor IC

B_OP:3.0mT, B_RP:-3.0mT, S6 Package

AEC-Q100, Speed+Speed, BV>60V

SC2527-SD

Dual-Channel Speed and Direction Output Hall Sensor IC

B_OP:3.0mT, B_RP:-3.0mT, S6 Package

AEC-Q100, Speed+Direction, BV>60V

SC2526-AB

Dual-Channel Speed and Speed Output Hall Sensor IC

B_OP:-3.0mT, B_RP:3.0mT, TO-94 Package

AEC-Q100, Speed+Speed, BV>60V

SC2526-SD

Dual-Channel Speed and Speed Output Hall Sensor IC

B_OP:-3.0mT, B_RP:3.0mT, VB Package

AEC-Q100, Speed+Direction, BV>60V

SC2529-AB

100V High-Voltage 3D Dual-Channel Hall Sensor IC

B_OP:2.5mT, B_RP:2.5mT, VB/S6 Package

AEC-Q100,ASIL B, Speed+Speed, XY Active, BV>100V

SC2529-SD

100V High-Voltage 3D Dual-Channel Hall Sensor IC

B_OP:2.5mT , B_RP:2.5mT, VB/S6 Package

AEC-Q100,ASIL B, Speed+Direction, XY Active, BV>100V

SC2528-AB

100V High-Voltage 3D Dual-Channel Hall Sensor IC

B_OP:2.5mT , B_RP:2.5mT, VB/S6 Package

AEC-Q100,ASIL B, Speed+Speed, ZX Active, BV>100V

SC2528-SD

100V High-Voltage 3D Dual-Channel Hall Sensor IC

B_OP:2.5mT , B_RP:2.5mT, VB/S6 Package

AEC-Q100,ASIL B, Speed+Direction, ZX Active, BV>100V

View all products >

3. Latch Switch Hall

SC2943

High-Performance Digital Latch Hall-Effect Sensor

2.8V~40V, B_OP:3.0mT , B_RP:-3.0mT
SO/UA Package

AEC-Q100,ASIL B, High sensitivity, BV>60V

SC2948

High Voltage Withstand, Reverse Protection, High ESD Latch Hall Sensor IC

2.8V~40V, B_OP:8.0mT , B_RP:-8.0mT
SO/UA Package

AEC-Q100, ASIL B, BV>60V

SC2919

High-Reliability 200V Voltage-Withstanding Latch Hall Sensor IC

4.0V~120V, B_OP:7.0mT , B_RP:-7.0mT, SO/UA Package

AEC-Q100. Ultra-high voltage, ESD>12kV

SC25898

2-Wire High Performance Programmable Hall Sensor IC

4.0V~24V, B_OP:8.0mT , B_RP:-8.0mT
SO,UA Package

AEC-Q100, 2-wire Current,output, 4mA/26mA, BV>60V

SC2498T

Planar magnetic sensing Hall effect sensor

2.5V~40V, B_OP:3.0mT ,B_RP:-3.0mT
SO Package

AEC-Q100, Planar magnetic sensing, IDD=4.0mA, BV>60V

SC2443

High-Performance Digital Latch Hall-Effect Sensor

2.5V~24V, B_OP:3.0mT , B_RP:-3.0mT
SO/UA Package

AEC-Q100, Good sensitivity consistency

SC2402

High-Sensitivity, Small-Package Digital Latch Hall Sensor IC

2.5V~18V, B_OP:2.0mT, B_RP:-2.0mT, -40~125℃, DN/SO/UA Package

AEC-Q100, Good sensitivity consistency

SC2202

High-Sensitivity, Built-in Pull-Up Digital Latch Hall Sensor IC

2.5V~24V, B_OP:1.5mT, B_RP:-1.5mT
-40~125℃, SO/UA Package

AEC-Q100, Built-in pull-up resistor

View all products >

4. Omnipolar Switch Hall

SC2459-M

High-Performance Programmable Omnipolar Switch Hall Sensor IC

3.0V~40V, B_OP:PROG, B_RP:PROG, -40~150℃

AEC-Q100,ASIL B，BOP/BRP EOL Programmable

SC2450-ML

High-Sensitivity, High-Performance Omnipolar Micro-Power Hall Sensor IC

3.0V~40V, B_OP:±2.5mT, B_RP:±1.5mT, -40~150℃

AEC-Q100,ASIL B，Low power

SC2450-MLI

High-Sensitivity, High-Performance Omnipolar Micro-Power Hall Sensor IC

3.0V~40V, B_OP:±2.5mT, B_RP:±1.5mT, -40~150℃

AEC-Q100,ASIL B，Low power with inverter output

SC2450-M

High-Sensitivity, High-Performance Omnipolar Micro-Power Hall Sensor IC

3.0V~40V, B_OP:±2.5mT, B_RP:±1.5mT, -40~150℃

AEC-Q100, ASIL B, High sensitivity, frequency>10kHz

SC2462

High-Sensitivity Omnipolar Hall Sensor IC

2.5V~24V, B_OP:±2.5mT, B_RP:±1.5mT,
-40~150℃

AEC-Q100, High sensitivity, Good temperature stabilit

SC2466

High-Sensitivity Omnipolar Hall Sensor IC

2.5V~24V, B_OP:±16.5mT, B_RP:±13.5mT, -40~150℃

AEC-Q100, Low sensitivity, Good temperature stabilit

SC2062

Ultra-Low Power Omnipolar Hall Sensor IC

1.8V~5.5V, B_OP:±1.8mT, B_RP:±1.0mT,
-40~85℃

Micropower, OD Output

SC2061

Ultra-Low Power Omnipolar Hall Sensor IC

1.8V~5.5V, B_OP:±1.8mT, B_RP:±1.0mT,
-40~85℃

Micropower,PP Output

View all products >

5. Unipolar Switch Hall

SC2459

High-Performance Programmable Hall Effect Sensor

3.0V~40V, B_OP:PROG , B_RP:PROG
-40~150℃

AEC-Q100, ASIL B, BOP/BRP EOL Programmable

SC2452

High-Performance Unipolar Hall Effect Sensor

3.0V~40V, B_OP:10mT, B_RP:8.5mT,
SO/UA Package

AEC-Q100,ASIL B, High reliability, BV>60V

SC2451

High-Performance Unipolar Hall Effect Sensor

3.0V~40V, B_OP:10mT, B_RP:8.5mT
SO/UA Package

AEC-Q100,ASIL B, High reliability, BV>60V

SC2450

High-Performance Unipolar Hall Effect Sensor

3.0V~40V, B_OP:2.5mT,B_RP:1.5mT,SO/UA Package

AEC-Q100,ASIL B, High reliability, High sensitivity, BV>60V

SC25893

2-Wire Current Unipolar Hall Sensor IC

3.3V~24V, B_OP:9.0mT, B_RP:7.5mT
SO/UA Package

AEC-Q100,ASIL B, 2-wire Current Output

SC25899

2-Wire Current Programmable Unipolar Hall Sensor IC

3.0V~40V, B_OP:PROG mT, B_RP:PROG mT, SO/UA Package

AEC-Q100,ASIL B, 2-wire Current Output, BOP/BRP EOL Programmable

SC2434

Unipolar Hall Sensor IC

2.5V~24V, B_OP:7.0mT, B_RP:5.5mT
SO/UA Package

AEC-Q100，S/N pole optional

SC2033

Ultra-Low Power Unipolar Hall Sensor IC

1.65V~5.5V, B_OP:2.2mT, B_RP:1.8mT
-40~85℃, SO Package

Micropower
