SC60410

High-Speed Inductive Sin/Cos Output Position Sensor Chip

Non-contact、High-speed、High-precision inductive position sensor

The SC60410 is a series of non-contact, highspeed, high-precision inductive position sensor ICs designed for high-speed absolute position sensing in automotive and industrial applications. Based on the eddy-current effect principle, the device accurately measures target position by detecting changes in induced voltage caused by the displacement of a metallic target over a set of coils

data table

SC60410-Q_EN.pdf

download

Characteristics and advantages Ordering Information Product Application Documents and Resources

Characteristics and advantages

AEC-Q100 Grade0 automotive grade qualified

Compliant with ISO26262 Functional Safety ASIL-B

Supports maximum rotational speed exceeding 600K rpm

Accuracy ≤±0.36°el, maximum ≤0.05°

Supports Auto-Calibration Function

Programmable via Single-Wire Interface through Power Pin or Programming Pin

Diagnostic functions: open circuit, short circuit, overvoltage, overtemperature，overcurrent，coil Input open-circuit

High-reliability design: 48V voltage tolerance for power and output pins

Strong anti-electromagnetic interference capability

Suitable for compact through-shaft mounting configuration

Operating temperature range: -40℃ to 150℃

Ordering Information

Ordering Information	Mark	Output	Ambient(℃)	Package	Pack	Amount
SC60410TG-TR-Q	60410	±SIN/COS	-40~150	TSSOP16	Tape&Reel	3000Pcs/Reel
SC60410QC-TR-Q	60410	±SIN/COS	-40~150	QFN3*3-16	Tape&Reel	5000Pcs/Reel

Product Application

Motor Encoder

Robotic Arm

Main Inverter

Electric Power Steering (EPS)

Documents and Resources

Product selection guide

Semiment Product Selection Guide V1-25Q4.pdf

Selection Guide download

2025-12-9

Product Specification

SC60410-Q_EN.pdf

Datesheet download

2026-3-26

Application Documents

SC60410
