SC60218

Sine and Cosine Output、High Speed 14-Bit Magnetic Rotary Encoder IC

Contactless, high-speed, high-precision magnetic encoder, outputs various position signals

SC6021X is a non-contact, high-speed, high-precision magnetic encoder chip series with a built-in Hall induction point matrix in the center of the chip, which generates sine and cosine position signals by sensing a pair of pole magnets above the chip. The analog-to-digital conversion circuit inside the chip samples the amplified sine and cosine signals, the DSP circuit performs angle calculations, and finally outputs various position signals. The SC6021X has a resolution of 14-bit and supports up to 200K rpm.
